Zebra VC8300
Forklift Terminals
Ultra-rugged forklift computer
Designed for extreme environments with IP66 protection and operation from approximately -30°C to 50°C.
Seamless Android migration for TE apps
Runs existing terminal emulation apps directly and converts green screens to touch apps with All-Touch Terminal Emulation.
Excellent readability and operation
8″ WXGA touchscreen with approximately 1000 nits, suitable for glove use, and integrated keyboard in one compact housing.
Product information
The Zebra VC8300 is an ultra-rugged Android vehicle terminal offered by Codipack for mounting on forklifts and other warehouse vehicles. The device is developed to replace older Windows or traditional terminal emulation solutions and makes the transition to Android simple, without requiring immediate adaptation of existing back-end systems. Thanks to the bright 8″ WXGA touchscreen with high light output, the screen remains readable in virtually all lighting conditions, both indoors and outdoors in the warehouse or on the loading dock.
The VC8300 is mainly deployed on forklifts in distribution centers, manufacturing, cold and freezer environments, ports, and 3PL logistics to provide real-time access to inventory data, location information, and order picking assignments. Users can work via the integrated, illuminated keyboard or via the touchscreen, depending on the application and preference. The device supports Android with Zebra Mobility DNA and LifeGuard, enabling long-term security and software updates. The VC8300 integrates via WLAN, Bluetooth, and wired interfaces with existing WMS, ERP, and terminal emulation environments, allowing seamless incorporation into ongoing warehouse processes.
Show more
Specifications
Operating system: Android 11, upgradeable to Android 14.
Processor: Qualcomm Snapdragon 660 octa-core, 2.2 GHz.
Memory: 4 GB RAM and 32 GB Flash storage.
Display: 8″ WXGA (1280 x 720) capacitive touchscreen with approx. 1000 nits brightness.
Ruggedness: IP66 sealing against dust and water, designed for heavy shocks and vibrations.
Temperature range: Operating approx. from -30°C to 50°C, options with integrated heating for freezer environments.
Input: Integrated, interchangeable alphanumeric keyboard plus touchscreen control.
Wireless communication: WLAN (Wi-Fi), Bluetooth 5.0 for network and peripheral connection.
Wired interfaces: USB 3.0, USB 2.0, RS232 COM; optional Ethernet.
Dimensions and weight: Approx. 276 mm (W) x 238 mm (H) x 90 mm (D), weight approx. 3.7 kg.
Power options: Internal power converter and mounting solutions for direct connection to vehicle power.
Support: Zebra Mobility DNA and LifeGuard for Android for management, security, and long lifecycle updates.
Downloads
Frequently asked questions
Coding and labeling are our core business. We have 5000 customers in very diverse sectors: from the local cheese trader to the multinational.
For which environments is the Zebra VC8300 suitable?
The VC8300 is designed for use on forklifts and vehicles in warehouses, manufacturing, loading docks, outdoor areas, cold and freezer storage, and 3PL environments, with a rugged housing and wide temperature range.
Can the VC8300 run my existing terminal emulation (TE) applications?
Yes, the VC8300 supports TE applications directly and can run green screen applications without back-end adjustments, while All-Touch Terminal Emulation can convert them to modern touch interfaces.
Which connectivity options does the VC8300 offer?
The device supports Wi-Fi for wireless network connection, Bluetooth 5.0 for peripherals, multiple USB and RS232 ports, and optional Ethernet for wired integration.
Is the Zebra VC8300 suitable for glove use and cold environments?
Yes, the 8″ capacitive touchscreen is suitable for glove use and configurations with integrated heating are available, making the device deployable in cold and freezer environments.
