Diagraph ResMark 5000
High resolution
Easy printhead replacement
The improved printhead design allows for quick replacement between Mark 2 and Mark 4 printheads, minimizing downtime.
High resolution on porous surfaces
Prints consistent, sharp images up to 300 dpi on cardboard, gypsum, cellulose or wood in challenging industrial environments.
Maximum availability
Automatic flushing function and ink circulation system ensure bubble-free ink and clean printheads, even in dusty environments.
Product information
The Diagraph ResMark 5000 is a high-resolution industrial inkjet printer that prints sharp, durable messages, barcodes and graphics on porous surfaces such as cardboard, ideal for end-of-line case coding. This system solves the problem of inconsistent print quality in rough industrial settings, such as dairy production, through robust technology that guarantees 24/7 reliable operation with print speeds up to 150 fpm for barcodes and 200 fpm for text.
Applications include large character coding with print images up to 100 mm high per printhead (up to 8 heads), suitable for texts, codes, logos and barcodes (UPC, GTIN, Code 128, Datamatrix, QR-Code). It integrates easily via Ethernet, WLAN, I/Os or software such as NextConnect and Loftware Nicelabel, and retrieves print data directly from merchandise management systems or PCs. The printer supports Mark 2 (up to 51 mm print height) and Mark 4 (up to 102 mm) printheads with a print distance up to 12 mm.
Show more
Specifications
Technology: Piezoelectric print module (Trident).
Print resolution: Up to 300 dpi horizontal, 64 dpi vertical.
Printheads: Mark 2 (up to 51 mm high), Mark 4 (up to 102 mm high), up to 8 per controller.
Print speed: Up to 90 m/min (depending on head).
Print distance: Maximum 12 mm to product.
Applications: Large characters, codes, logos on porous surfaces such as cardboard, wood; barcodes (UPC, GTIN, Code 128, Datamatrix, QR).
Interfaces: Ethernet, WLAN, I/Os.
Software: NextConnect, Loftware Nicelabel; Windows-based GUI.
Ink: ScanMark (mineral oil-free), with recirculation and flushing function.
Environment: Suitable for dusty, rough settings with automatic cleaning and spring mounting.
Frequently Asked Questions
Below you will find the most frequently asked questions about GSI Colorize and how it improves your printing and packaging processes.
What technology does the ResMark 5000 use?
The printer uses a piezo-electric print module (Trident) for impulse jet printing on porous surfaces.
On which surfaces does the system print?
It prints on porous materials such as cardboard, gypsum, cellulose or wood, with a robust design for industrial environments.
What resolution and print size does it offer?
Up to 300 dpi horizontal with print images up to 100 mm high per printhead.
How does it integrate into production lines?
Via Ethernet, WLAN, I/Os or software such as Loftware Nicelabel, with data from management systems or PCs.
