Zebra ZT620
Industrial Label Printers
Extremely wide print capacity
Up to 8.5 inches (216 mm) print width for large pallet labels and shipping documents.
Maximum print speed
Up to 14 ips (356 mm/s) for highest industrial productivity.
Advanced Link-OS touchscreen
4.3-inch full-color display with Print DNA Enterprise cloud management.
Product information
The Zebra ZT620 is the most powerful industrial barcode printer offered by Codipack for the most demanding labeling applications in harsh production and logistics environments. With thermal transfer and direct thermal technology the printer supports extremely wide media up to 8.5 inches (216 mm) width with resolutions of 203 dpi (14 ips) and 300 dpi. The all-metal construction with E3™ printhead technology and bi-fold door ensure unmatched reliability.
The printer processes continuous, die-cut, gap, black-mark and linerless media up to 20 inches (508 mm) roll capacity with automatic calibration and optional RFID encoding. USB 2.0, RS-232, Ethernet, dual Bluetooth and Wi-Fi/802.11ac connectivity provide complete network flexibility with ZPL II, EPL and Print DNA Enterprise software. The 4.3-inch full-color touchscreen with real-time cloud monitoring maximizes uptime and productivity.
Show more
Specifications
Print technology: Thermal transfer and direct thermal.
Print resolution: 203 dpi (8 dots/mm), 300 dpi (12 dots/mm).
Print speed: Max. 14 ips (356 mm/s).
Print width: Max. 8.5 inches (216 mm).
Print length: Up to 150 inches (3810 mm).
Media types: Continuous, die-cut, gap, black-mark, linerless.
Media capacity: Up to 20 inches (508 mm) OD on 3-6 inch core.
Ribbon length: 1476 ft (450 m).
Connectivity: USB 2.0, RS-232, Ethernet, Bluetooth LE, Wi-Fi.
Memory: 2 GB RAM, 8 GB Flash.
Operation: 4.3″ full-color touchscreen.
Extra: RFID UHF, Print DNA Enterprise, IP43.
Downloads
Frequently asked questions
Coding and labeling is our core business. We have 5000 customers in very diverse sectors: from the local cheese shop to the multinational.
What makes the ZT620 suitable for the widest labels?
Supports up to 8.5 inches (216 mm) print width for large pallet labels and shipping documents.
How fast does the ZT620 print?
Up to 14 ips (356 mm/s) at 203 dpi for maximum industrial productivity.
Which connectivity options does the printer offer?
USB 2.0, RS-232, Ethernet, dual Bluetooth LE and Wi-Fi/802.11ac.
Is the ZT620 suitable for RFID applications?
Yes, with optional UHF RFID encoding for combined barcode/RFID labels.
